Omron | NX-TC3406 | NX-series Temperature Control Unit
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
Engineered for the rigorous demands of industrial automation and process control, the Omron NX-TC3406 stands out as a highly versatile 4-channel temperature control unit. It adeptly handles both heat and cool applications; furthermore, its broad sensor compatibility, encompassing numerous thermocouple types and Pt100/Pt1000 RTD inputs, ensures exceptional flexibility. With reliable PNP digital outputs and convenient push-in plus terminals, installation on DIN rails becomes remarkably straightforward, ultimately streamlining system integration and significantly boosting operational efficiency. This unit incorporates adaptive control technology, allowing for optimal PID adjustment throughout operation, which in turn helps to consistently maintain ideal process conditions, moving beyond traditional, experience-dependent tuning.
| Parameter | Specification |
|---|---|
| Number of Channels | 4 channels |
| Input Types | Thermocouple (K, J, T, E, L, U, N, R, S, B, C/W, PLII), Pt100, JPt100, Pt1000 |
| Digital Output Type | PNP, PWM, Voltage output (for driving SSR) |
| Number of Digital Outputs | 4 points |
| Rated Output Voltage | 24 VDC |
| Maximum Load Current | 21 mA/point, 84 mA/Unit |
| Conversion Time | 50 ms/unit |
| Control Function | Heat or Cool |
| I/O Connection Type | Push-in Plus terminals / Screwless clamp terminal block |
| Degree of Protection (IP) | IP20 |
| Mounting Method | DIN rail |
| Dimensions (H x W x D) | 100 mm x 24 mm x 71 mm |
| Operating Temperature | 0 to 55 ¡ãC |
| Power Consumption | 1.70 W max (connected to CPU Unit) / 1.25 W max (connected to Communications Coupler Unit) |
