Omron | NX-PG0332-5 | Pulse Output Unit
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
The Omron NX-PG0332-5 pulse output unit stands out as a critical component for sophisticated motion and factory automation applications, meticulously engineered to guarantee exceptional signal transmission reliability. This unit boasts four NPN line driver pulse outputs and incorporates two robust MIL connectors, ensuring secure and straightforward integration into diverse systems. It truly excels in environments demanding not only high-speed but also incredibly accurate pulse generation, perfectly suited for everything from intricate machine control setups to comprehensive process monitoring. Moreover, its thoughtfully compact design significantly streamlines deployment, allowing for seamless integration within existing Omron NX Series configurations, thereby enhancing overall control and monitoring capabilities.
| Parameter | Specification |
|---|---|
| Product Type | Pulse Output Unit (Line Driver Output, NPN type) |
| Number of Channels | 4 Channels |
| Output Type | Line Driver Pulse (NPN) |
| Maximum Pulse Frequency | 4 MHz (4 Mpps) |
| Digital Inputs | 5 per channel (External inputs) |
| Digital Outputs | 4 Pulse Outputs + 12 External Outputs (3 per channel) |
| External Connections | 2 x MIL Connectors (34 terminals each) |
| Dimensions (W x H x D) | 30 ¡Á 100 ¡Á 71 mm |
| Degree of Protection (IP) | IP20 |
| Operating Temperature | 0 to 55¡ãC |
| Max Line Driver Cable Length | 10 m |
| Power Supply | Supplied from NX bus |
| Current Consumption (I/O Power Supply) | 50 mA/CH max |
| Mounting Type | DIN Rail Mounting |
| Standards Compliance | cULus Class I Division 2, RoHS, CE, UL, CUL, CSA, IEC 61131-2 |
