Omron | NX-OD3268 | Transistor Output Unit
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
Engineered for the demands of modern industrial automation, the Omron NX-OD3268 stands out as a high-performance 4-point PNP transistor output unit. This robust module seamlessly integrates into NX Series systems, delivering reliable 24 VDC control with a compact, space-saving design; furthermore, its precise output capabilities are perfectly suited for demanding machine automation and process control applications.
| Parameter | Specification |
|---|---|
| Model | NX-OD3268 |
| Unit Type | Transistor Output Unit |
| Number of Digital Outputs | 4 points |
| Output Type | PNP |
| Rated Output Voltage | 24 VDC |
| Permitted Operating Voltage Range | 15.0 to 28.8 VDC |
| Output Current per Point | 2 A |
| Max Total Output Current per Unit | 8 A |
| I/O Refreshing Method | Switching Synchronous I/O refreshing and Free-Run refreshing |
| Connection Type | Screwless Clamping Terminal Block (16 terminals) |
| Dimensions (W x H x D) | 12 mm x 100 mm x 71 mm |
| Protection Class | IP20 |
| OFF-to-ON Response Time | 0.5 ms max. (500 ¦Ìs) |
| ON-to-OFF Response Time | 1.0 ms max. (1 ms) |
| Certifications | RoHS, cULus (Class I Division 2), EC Directives, NK, Lloyd, RCM, KC |
