Omron | NX-DA3605 | Analog I/O Unit
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
Engineered for exacting control in advanced automation environments, the Omron NX-DA3605 is an indispensable analog output unit, perfectly complementing both Sysmac Machine Automation Controllers and CJ2-Series PLCs. This robust module boasts four analog voltage outputs, effortlessly ranging from -10 to 10 V, and delivers exceptional precision thanks to its impressive 15-bit resolution. Furthermore, its rapid 0.04 ms/unit conversion time ensures dynamic, real-time signal processing, which is crucial for high-speed applications. Installation is remarkably streamlined with its screwless push-in terminals, while the compact 12 mm width significantly conserves cabinet space, offering considerable flexibility for diverse industrial setups. Ultimately, the NX-DA3605 truly excels in critical industrial automation, machine control, and sophisticated process management systems, thereby providing reliable and efficient analog signal handling.
| Parameter | Specification |
|---|---|
| Module Type | Analog Output Unit (Voltage) |
| Number of Analog Outputs | 4 |
| Analog Output Range | -10 to 10 V |
| Output Resolution | 15 Bit (1:30000) |
| Conversion Time | 0.04 ms/unit |
| I/O Refresh Method | Selectable Synchronous or Free-Run |
| Connection Type | Screwless Push-in Terminals |
| Supply Voltage (DC) | 24 VDC |
| Degree of Protection | IP20 |
| Width | 12 mm |
| Height | 104.5 mm |
| Depth | 80.1 mm |
| Power Consumption | 1.25 W max |
