Omron | E6B2-CWZ6C DC5-24 20P/R | Incremental Rotary Encoder
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
This Omron E6B2-CWZ6C DC5-24 20P/R incremental rotary encoder is a prime choice for precise motion control, delivering accurate feedback signals essential for motor control, robotic systems, and various automated machinery. Furthermore, its robust design ensures dependable operation across a wide range of industrial environments.
| Parameter | Specification |
|---|---|
| Product Type | Incremental Rotary Encoder |
| Resolution | 20 P/R (Pulses Per Revolution) |
| Output Configuration | NPN Open-Collector Output |
| Power Supply Voltage | 5-24 VDC (-5% to +15%), ripple (p-p) 5% max. |
| Current Consumption | 80 mA max. |
| Output Phases | A, B, and Z Phases |
| Max. Response Frequency | 100 kHz |
| Permissible Rotational Speed | 6000 r/min (rpm) |
| Protection Class | IP50 (IEC 60529) |
| Shaft Diameter | 6 mm |
| External Diameter | 40 mm |
| Starting Torque | 0.98 mN¡¤m max. |
| Ambient Temperature Range | Operating: -10 to +70¡ãC, Storage: -25 to +85¡ãC |
| Connection Method | Pre-wired (2m Cable Length) |
