Omron | E6B2-CWZ6C 360P/R | Incremental Rotary Encoder
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
When seeking accurate rotational feedback in demanding industrial environments, the Omron E6B2-CWZ6C 360P/R emerges as a top-tier choice. This incremental rotary encoder, boasting a compact 40mm diameter, is engineered to provide highly reliable position and speed detection across a wide array of applications. Its solid shaft design ensures robust performance, while the NPN open-collector output, providing A, B, and Z phases, delivers the precision control engineers depend on for critical automation tasks. Furthermore, with built-in protection against short circuits and reverse polarity, this encoder offers enhanced operational longevity and safety, making it an incredibly versatile component for integrating into complex machinery and systems where consistent, precise data is paramount.
| Parameter | Specification |
|---|---|
| Encoding Method | Incremental Shaft Model |
| Resolution | 360 Pulses Per Revolution (P/R) |
| Output Phases | A, B, Z |
| Control Output | NPN Open Collector |
| Power Supply Voltage | 5 to 24 VDC (-5% to +15%, ripple (p-p) 5% max.) |
| Current Consumption | 80 mA max. |
| Max. Response Frequency | 100 kHz |
| Max. Permissible Rotation | 6000 r/min (rpm) |
| Shaft Diameter | 6 mm |
| External Diameter | 40 mm |
| Connection Method | Pre-wired cable (0.5m or 2m options) |
| Protective Circuits | Output short-circuit, Power supply reverse polarity |
| Operating Temperature | -10 to 70 ℃ (no icing) |
| Degree of Protection | IP50 |
| Starting Torque | 0.98 mN¡¤m max. |
| Shaft Loading (Radial/Thrust) | 30 N / 20 N |
| Housing Material | ABS Case, Aluminum Body, SUS420J2 Shaft |
