Omron | CJ1W-TC103 | Temperature Control Unit
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
Optimized for precise thermal management, the Omron CJ1W-TC103 stands as a pivotal component for industrial automation systems, effectively handling heating and cooling processes. This compact unit offers dual-loop temperature control, accommodating Pt100 RTD inputs and providing reliable NPN transistor outputs, furthermore enhancing operational safety with its integrated heater burnout detection capabilities.
| Parameter | Specification |
|---|---|
| Model | CJ1W-TC103 |
| Unit Type | Special I/O Unit, Temperature Control Module |
| Input Type | 2 x Platinum Resistance Thermometer (Pt100 / JPt100) |
| Output Type | 2 x Digital Outputs (24Vdc, NPN Transistor/Open-Collector) |
| Control Loops | 2 Loops |
| Control Function | PID Control (2 degrees of freedom) or ON/OFF control |
| Special Functions | Heater Burnout Detection Function |
| Supply Voltage (DC) | 20.4-26.4Vdc (24Vdc nominal) |
| Current Consumption (5Vdc) | 0.25 A max |
| Mounting Type | DIN Rail |
| Termination Style | Screw Terminal (Removable M3 terminal block connections) |
| Degree of Protection | IP20 |
| Dimensions (HxWxD) | 90mm x 31mm x 65mm |
| Weight | 0.331 lb (150.14 g) |
| Compliant Standards | cULus (Class I Division 2), CE, Lloyd, NK |
