Omron | CJ1W-OD262 | Transistor Output Unit
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
When precise control over a multitude of devices is paramount, the Omron CJ1W-OD262 digital output module steps in, offering an impressive 64 points of 24V DC PNP/Sourcing transistor outputs. Engineered for seamless integration within Omron's CJ-series PLCs, this unit facilitates high-speed, reliable switching for a diverse array of industrial applications, spanning from intricate machine automation to expansive process control systems. Furthermore, its photocoupler isolation method ensures enhanced system stability and protection against electrical noise.
| Parameter | Specification |
|---|---|
| Model | CJ1W-OD262 |
| Number of Outputs | 64 (Transistor, PNP/Sourcing Type) |
| Rated Voltage | 12 to 24 VDC |
| Operating Load Voltage Range | 10.2 to 26.4 VDC |
| Max Output Current per Point | 0.3 A |
| Max Output Current per Common | 1.6 A |
| Max Output Current per Unit | 6.4 A |
| Response Time (ON) | 0.1 ms |
| Response Time (OFF) | 0.3 ms |
| Isolation Method | Photocoupler |
| Power Consumption (Internal 5V DC) | 110 mA |
| Mounting Type | DIN rail (CJ-series PLC rack) |
| I/O Connection Type | MIL connectors (plug not included) |
| Number of I/O Connectors | 2 |
| Protection Class | IP20 |
| Operating Temperature | 0 to 55¡ãC |
| Dimensions (H x W x D) | 90 x 31 x 83.6 mm |
