FX3U-4AD-ADP | Mitsubishi| Analog Input Special Adapter
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
Unlock enhanced monitoring capabilities with the Mitsubishi FX3U-4AD-ADP, an essential analog input special adapter meticulously designed for the MELSEC FX3U Series programmable logic controllers. This robust module provides four independent analog input channels, which can each be flexibly configured for either voltage (0-10V DC) or current (4-20mA DC) signals. Indeed, its impressive 12-bit resolution for voltage inputs, complemented by 11-bit resolution for current, ensures exceptional precision across a broad spectrum of industrial measurement tasks, from process control to robotics and automotive applications. Furthermore, its compact form factor and DIN rail or direct mounting options allow for seamless integration into existing systems, minimizing installation complexities while maximizing operational efficiency.
| Parameter | Specification |
|---|---|
| Product Type | Analog Input Special Adapter |
| Number of Analog Inputs | 4 channels |
| Voltage Input Range | 0-10V DC (Input resistance: 194 k¦¸) |
| Current Input Range | 4-20mA DC (Input resistance: 250¦¸) |
| Digital Output (Voltage) | 12 bits, binary |
| Digital Output (Current) | 11 bits, binary |
| Resolution (Voltage) | 2.5mV (10V/4000) |
| Total Accuracy (Voltage, 25¡ãC) | ¡À0.5% (¡À50mV) for 10V full scale |
| A/D Conversion Time (FX3U/FX3UC PLC) | 200¦Ìs (Data updated every scan time) |
| Internal Power Supply (from main unit) | 5V DC, 15mA |
| External Power Supply | 24V DC +20%/-15%, 40mA |
| Operating Ambient Temperature | 0 to 55¡ãC |
| Dimensions (W x H x D) | 17.6 mm x 90 mm x 89.5 mm |
| Weight | 0.1 kg |
| Certifications | CE, UL/cUL, UKCA Compliant |
