FX3U-422-BD | Mitsubishi| Extension board for RS-422 communication
Condition: New Original Packaging
Ellglble For 1-3 Business days Shipping
100,000+ genuine producls in stack. More about shipping→
All Parts Come with 12-Month Warranty
Industy-leading protection. More about warranty→
New, Refurbished & Pre-owned Items Available
Multiple opions to meet your needs and budget
Unlock enhanced connectivity for your Mitsubishi FX3U PLC systems with the FX3U-422-BD, a robust RS-422 communication expansion board. This compact module seamlessly integrates into the front left corner of the FX3U base unit, immediately expanding your system's communication capabilities. It's truly indispensable, providing a dedicated second programming port that cleverly allows simultaneous connection of both an operator panel (HMI) and a programming PC, thus streamlining diagnostics and operational control. Furthermore, its reliable design, drawing power directly from the main unit, ensures consistent performance in demanding industrial environments.
| Parameter | Specification |
|---|---|
| Interface Type | RS-422 Communication Board |
| Compatibility | Mitsubishi FX3U PLCs (Ver.2.20+), FX3UC-32MT-LT (Ver.1.00+), FX3UC-32MT-LT-2 (Ver.2.53+) |
| Mounting Location | Clips into front left corner of FX3U base unit |
| Power Supply | 5V DC from PLC main unit internal power supply |
| Current Consumption | 20 mA (from 5V DC supply) |
| Communication Standard | Conforms to RS-422 |
| Communication Method | Half-duplex |
| Max. Transmission Distance | 50 meters (164 ft) |
| Connection Method | 8-pin Mini DIN (female) |
| Insulation | Not isolated (between communication line and CPU) |
| Dimensions (W x H x D) | 19.6 mm x 46.1 mm x 53.5 mm |
| Weight | Approx. 0.02 kg (20g) |
